Carbex 2008-40-SW-KIT Carbon Grounding Brush

Part No. 2008-40-SW-KIT

Carbex 2008-40-SW-KIT silver graphite shaft grounding brush kit for wind turbine generators. It diverts stray shaft currents to ground, prevents bearing electrical pitting damage, low friction, long service life for onshore & offshore wind turbine operation. Direct replacement alternative for Schunk S13/F19, LFC554/A620, full assembly kit ready for installation.

Material	Silver Graphite
Dimensions	20mm × 8mm × 64mm, Radius R70mm, assembled kit with lead wire
Application	Shaft grounding for wind turbine generators, compatible with Siemens, Nordex, Senvion, Loher, Winergy, VEM wind turbines. Protect rolling bearings from stray shaft current & electrical erosion, eliminate static charge for rotating electrical machinery
Voltage	AC / DC up to 1000V
Current Density	2 – 6 A/cm²
Speed	Peripheral speed up to 30 m/s
Hardness	Shore 35 – 45
Grade	Silver Graphite Grade
Connection	Cable bonded assembly connection
Lead Type	Flexible insulated copper lead, pre-assembled in kit
Spring	Pre-fitted constant force spring (complete kit assembly)

Request a Quote Related Products

48h Sample Dispatch 60+ Countries Served Datasheet Included

Technical Specifications

Product Model	Carbex 2008-40-SW-KIT
Material	Silver Graphite
Dimensions	20mm × 8mm × 64mm, Shaft Radius R70mm
Application	Wind turbine shaft grounding, Siemens, Nordex, Senvion, Loher, Winergy, VEM generators
Working Voltage	AC / DC up to 1000V
Current Density	2 – 6 A/cm²
Max Peripheral Speed	30 m/s
Hardness	Shore 35 – 45
Brush Grade	Silver Graphite Grade
Connection Type	Cable bonded assembly connection
Lead Type	Flexible insulated copper lead (pre-assembled kit)
Spring	Pre-installed constant force spring, full kit assembly
Equivalent Grade	Replaces Schunk S13/F19, LFC554/A620
Key Features	Stray shaft current diversion, bearing protection, low friction, offshore resistant, ready-to-fit kit
Quality Standard	Matches Carbex OEM specification

Description

The Carbex 2008-40-SW-KIT is a complete pre-assembled carbon grounding brush kit specially designed for wind turbine shaft grounding systems. Made of premium silver graphite material, it delivers ultra-low contact resistance, excellent electrical conductivity and self-lubricating sliding performance. The grounding brush safely bleeds harmful stray shaft currents away from generator bearings to ground, avoiding electrical erosion, pitting and premature bearing failure, which greatly reduces wind turbine downtime and maintenance cost. This kit comes fully assembled with carbon brush block, constant force spring and flexible copper lead wire, radius R70mm profile to match turbine shaft surface. It is widely used on Siemens, Nordex, Senvion, Loher, Winergy and VEM wind power generators. It serves as a drop-in replacement equivalent to Schunk S13/F19 and LFC554/A620. Stable performance is maintained even in harsh offshore high humidity, temperature-varying environments. Strict quality control ensures consistent wear rate and reliable long-term grounding performance. Bulk supply and worldwide shipping available for wind farm maintenance and OEM service.
