Leeson Carbon Brush Holder 900328.04 for 108020.00 Motor

Part No. 900328.04

Leeson 900328.04 carbon brush holder assembly (2-pack) for the Leeson 108020.00 DC motor — 90/180 V armature gearmotor class. Spring-loaded, easy-access brush holder design with bolt-on mounting; motor-series brush reference H100 (9.5×31.5×31.5 mm). Verify fitment.

Dimensions	H100, 9.5 × 31.5 × 31.5 mm
Application	Carbon brush holder assembly for Leeson 108020.00 DC motor — part of the Leeson 108xxx DC gearmotor family (90/180 V armature, PWM/SCR controller rated). Leeson brush holder design provides easy access to brushes and large oversized brushes fo
Voltage	Motor-class 90 / 180 V armature DC (115/230 V AC input, per Leeson DC catalo

Compatible Models

Leeson 108020.00 (DC motor — user-specified) Leeson 108022.00 / 108023.00 (gearbox motor series — verify) Leeson 108051.00 / 108052.00 / 108053.00 (gearbox motor series — verify) Leeson 108xxx-series DC gearmotors (90/180 V armature class — verify)

Request a Quote Related Products

48h Sample Dispatch 60+ Countries Served Datasheet Included

Technical Specifications

Leeson Carbon Brush Holder 900328.04 — for Motor 108020.00
Specification	Value
Product Type	Carbon brush holder assembly (2-pack)
OEM Part Number	Leeson 900328.04
Fits Motor	Leeson 108020.00 (DC motor)
Motor Series	Leeson 108xxx DC gearmotors (verify 108022/23/51/52/53.00)
Voltage Class	90 / 180 V armature DC (115/230 V input)
Brush Reference	H100, 9.5 × 31.5 × 31.5 mm (series ref — verify)
Design	Spring-loaded; easy brush access; bolt-on base
Quantity	2-pack (2P)
Material	Not specified — confirm (brass/copper alloy typical)
Dimensions	Not specified — confirm

* Part number, motor fit and design from Leeson catalog and aftermarket retail data. Holder dimensions and material pending confirmation.

Compatible Models

This Leeson Carbon Brush Holder 900328.04 for 108020.00 Motor is designed as a direct replacement for the following machine models and series:

Not sure if it fits your machine? Send us your equipment model, motor type or original part number — our engineers will confirm compatibility and advise the correct grade. Ask an engineer →

Description

Overview

Leeson 900328.04 carbon brush holder assembly (2-pack) for the Leeson 108020.00 DC motor — part of the Leeson 108xxx DC gearmotor family. Leeson's brush holder design provides easy access to brushes and uses large oversized brushes for long service life, with a removable bolt-on base.pim.galco.com

Fitment

Leeson 108020.00 (user-specified)
Leeson 108xxx-series DC gearmotors (108022.00 / 108023.00 / 108051.00 / 108052.00 / 108053.00 — verify)
Motor-series brush reference: H100, 9.5 × 31.5 × 31.5 mm
